OPTEQ Instruments

VTX110

Active FTTx Products

1-Port Gigabit XPON Terminal

Access to Passive Optical Network

GPON ONU,ITU-T G.984 Compliant

1*GE LAN

Compatible With Main-stream OLT Platforms

WAN Type : Dynamic IP/Static IP/PPPoE
DHCP : Server
Client
DHCP Client List
Address Reservation
Quality of Service: WMM, Bandwidth Control
Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ
VPN : 802.1Q tag VLAN
VLAN transparent mode/VLAN translation mode/VLAN trunk mode
Access Control: Parental Control
Local Management Control
Host List
Access Schedule
Rule Management
Firewall Security: DoS, SPI Firewall
IP Address Filter/MAC Address Filter/Domain Filter
IP and MAC Address Binding
VOIP Features: One RJ-11 FXS ports for connecting to analog telephones
Call forwarding, Call waiting, Call block, 3-way conference call, etc.
Management: Access Control, Local Management, Remote Management
Internet Protocol: IPv4, IPv6

GPON Standards: ITU-T G.984
Distance : 20Km Max
Data Rates: Upstream : 1.25Gbps, Downstream:2.5Gbps
Wireless Standards : IEEE802.11b/g/n,2.4GHz
Signal Rate: 2.4GHz:Up to 300Mbps
Operation Frequency : 2.4GHz
Reception Sensitivity : 2.4GHz
11g 54M: -77dBm
11n HT20: -74dBm, 11n HT40: -72dBm
Wireless Security : WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption
VOIP Standards : SIP (RFC3261), ITU-T G.729/G.722/G.711a/G.711
