VTX520-G

VTX520-G

Active FTTx Products

    AC1200 Wireless Gigabit XPON Router

    2*GE LAN

    Supports 80MHz Bandwidth

    EasyMesh R2

Download Catalogue
Main Image
Image 1 Image 1 Image 1

Characteristic

  • WAN Type:    Dynamic IP/Static IP/PPPoE
  • DHCP :   Server, Client, DHCP Client List, Address Reservation
  • Quality of Service :   WMM, Bandwidth Control
  • Port Forwarding:    Virtual Server, Port Triggering, UPnP, DMZ
  • VPN :   802.1Q tag VLAN, VLAN transparent mode/VLAN translation mode/VLAN trunk mode
  • Access Control:    Parental Control, Local Management Control, Host List, Access Schedule, Rule Management
  • Firewall Security:DoS, SPI Firewall
    IP Address Filter/MAC Address Filter/Domain Filter
    IP and MAC Address Binding
  • Management :   Access Control, Local Management, Remote Management
  • Internet Protocol:    IPv4, IPv6

Additonal

  • 1* VTX520-G Wireless Router
  • 1* Power Adapter
  • 1* Quick install guide
  • 1* LAN Cable

Specification

  • GPON Standards:    ITU-T G.984
  • Distance:    20Km Max
  • Data Rates:    Upstream:1.25Gbps, Downstream:2.5Gbps
  • Wireless Standards:   IEEE802.11a/n/ac,5GHz
  • IEEE802.11b/g/n,2.4GHz
  • Signal Rate:    5GHz:Up to 867Mbps
  • 2.4GHz:Up to 300Mbps
  • Operation Frequency:    2.4GHz and 5GHz
  • Reception Sensitivity : 5GHz
    11a 6Mbps : -96dBm, 11a 54Mbps: -79dBm
    11ac HT20: -71dBm, 11ac HT40: -66dBm, 11ac HT80: -63dBm,
    11n HT20: -72dBm, 11n HT40: -71dBm
    2.4GHz
    11g 54M: -77dBm
    11n HT20: -74dBm, 11n HT40: -72dBm
  • Wireless Security :  WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption
