OPTEQ Instruments

AE3100 A-F

OTDR

The AE3100 is a standalone OTDR ideal for verifying the construction, installation and maintenance of access networks, data centers, and FTTx networks. This handheld unit can be configured with both single mode and multi-mode options, and comes with Deviser’s FiberPathTM intelligent fiber analysis software, enabling technicians to find faults quickly and
accurately by simplifying the interpretation process of complex OTDR traces. OPM, VFL and Fiberscope options are available.

Characteristic

High performance OTDR for FTTx and RFoG networks
7”, 800x480 LCD touchscreen places power and convenience at your fingertips
Excellent short-distance performance with 0.8m event deadzone and 4m attenuation deadzone
Dual-wavelength testing with broad dynamic range coverage (28 - 45dB)
Minimum 5cm resolution
Intelligent event analysis
Excellent stability and repeatability
"FiberPath" fiber link mapping mode
Multiple options for your measurement needs, including: VFL, power meter, light source, and optical fiber microscope
Complete user data ports: supports LAN, USB, SD, & more

Additonal

Applications

Construction, deployment, maintenance, and authentication of the following networks:

FTTx
Long Haul Networks
Passive Optical Networks (PON)
Local Area Networks (LAN)
Metropolitan Area Networks (MAN)
